QP630 QP800 Single Head Magnetic PowderPay Off Rack

QP630 QP800 Single Head Belt Pay Off Rackare as follows: the outer diameter of the spool is available in two sizes: φ400 - 630mm and φ630 - 800mm; tension is controlled by a tension gun; the control method is belt brake/magnetic powder brake; the strength load is 400kg, and the standard load is 300kg.

Quantity:
Availability:





Inquire Add to Basket

Product Description

Technical Specifications of the QP630 QP800 Single Head Magnetic Powder Pay Off Rack

Parameter	Specification
Model	Japanese Type Single-Shaft Pay Off Rack (QP630 QP800 Series)
Spool Outer Diameter Range	φ400-630mm / φ630-800mm
Tension Control System	Static induction, magnetic automatic braking
Braking Control Method	Magnetic Powder Brake
Standard Load Bearing Capacity	300kg
Strengthened Load Bearing Capacity	400kg
Structure Type	Single Head / Single Shaft Horizontal Design
Compatible Equipment	Extruders, Wire Twisting Machines, Spooling Lines, Rewinding Machines
