The QP500/630 Servo Cable Coiling Machine is an intelligent, high-precision wire spooling solution built for industrial manufacturing enterprises with strict requirements for winding accuracy, process control, and continuous production compatibility. This servo-driven equipment is engineered to work seamlessly with high-speed extruder production lines, supporting a maximum line speed of 200m/min, and is compatible with standard PN100-PN500 industrial wire reels. Equipped with a professional servo cable laying system and intelligent PLC control, it delivers uniform, precision winding for even the most demanding cable production applications.
At the core of this servo-driven cable coiling machine is an advanced servo cable laying device, with fully adjustable laying distance and wiring width. Unlike traditional mechanical wiring systems, it enables precise control of winding pitch, ensuring perfectly aligned, uniform coil layers with zero overlapping or unevenness, even during high-speed continuous operation.
This PLC-controlled wire spooling machine comes with a Siemens or Huichuan PLC (optional) as its core control unit, paired with a Kunlun Tongtai 10-inch touch screen HMI. All critical parameters – including take-up speed, wiring pitch, meter counting, wiring start point, and wiring width – are fully adjustable and visualized in real time, simplifying operation and reducing operator training time.
Designed for 24/7 industrial operation, the equipment supports a maximum applicable line speed of 200m/min, making it ideal for high-volume, continuous cable extrusion lines. Its 2.2KW three-phase asynchronous motor and sine wave inverter deliver stable, low-vibration performance, minimizing maintenance needs and extending service life.
Featuring a platform top cone clamping mechanism, this industrial servo wire take-up machine offers fast, secure reel clamping and easy changeover. It is compatible with PN100-PN500 reels, with a reel outer width range of 50-375mm and a standard reel hole diameter of φ56mm, adapting to most standard industrial wire reel specifications.
Parameter | Specification |
Applicable Reel Specification | PN100-PN500; Reel Outer Width: 50-375mm; Reel Hole Diameter: φ56mm |
Maximum Applicable Line Speed | 200m/min |
Top Shaft Clamping Method | Platform Top Cone Clamping |
Cable Laying System | Servo cable laying device, adjustable laying distance and width |
Main Motor | Three-phase asynchronous motor, 380V, 2.2KW |
Core Electrical Components | Siemens PLC, Kunlun Tongtai 10-inch Touch Screen, Sine Wave Inverter |
PLC Brand Option | Siemens / Huichuan (customizable) |
This precision intelligent cable coiling equipment is widely deployed in high-demand industrial sectors, including new energy wiring harness manufacturing, high-end data communication cable production, building wire bulk processing, industrial automation cable assembly, and precision instrumentation wire production. It is the ideal choice for industrial production facilities that require strict meter counting accuracy, consistent winding quality, and seamless integration with automated extrusion production lines.
QIPANG (Shanghai Qipang Industrial Co., Ltd.) is a leading professional manufacturer of industrial wire and cable processing equipment, holding TUV, SGS, CE, and ISO certifications. Our core product line includes precision servo spooling machines, laser diameter gauges, high-precision wire length meters, cable spark testers, and wire preheaters, all engineered to integrate flawlessly with various extruder and automated production line systems. We have served industrial manufacturing enterprises worldwide for years, providing tailored, intelligent wire processing solutions that elevate production efficiency and quality.
We offer two industry-leading PLC options: Siemens and Huichuan, which can be customized to match your existing industrial control system.
The equipment supports a maximum applicable line speed of 200m/min, optimized for high-volume continuous extrusion production lines.
It is designed for a standard three-phase 380V power supply, equipped with a 2.2KW three-phase asynchronous motor for stable long-term operation.
It fits standard PN100-PN500 industrial reels, with a compatible reel outer width of 50-375mm and a standard reel hole diameter of φ56mm.
For industrial manufacturing enterprises seeking a high-precision, intelligent cable coiling solution that integrates seamlessly with your automated production line, our technical team is ready to deliver a tailored configuration. We can customize the PLC brand, reel compatibility, and control parameters of the QP500/630 Servo Cable Coiling Machine to meet your unique production requirements. Contact us today for a personalized consultation and quote.
